Persistence

State Model Persistence

In general, persistence is differentiated between static and dynamic state models. Some reasons can be found for the differentiation: - Static models are mainly used in the modelling/ designing phase, which requires more interaction with the model. Therefore, interaction with Excel files by the user is preferred. - Since the dynamic model arises with time considered (real world, simulation), the amount of data also enriches. - In the usage phase, faster alternatives are preferred. Since the interaction is stepped in the background, pickle files are preferred.

The high amount of cross-references in the state model makes it impossible to simply store the data in pickle files. A transformation/ serialization is required to transform the python objects into capsuled objects without direct links to other state model objects.

Static State Model (Excel) Mapper json file

{
  "target_schema": "xlsx",                  - resulting file type
  "reference_type": "label",                - label means that the labels/ static model ids are used as reference
  "sources": [                              - parameters of the state model python object
    {
      "source": "entity_types",             - a parameter of the state model python object
      "serialization_kind": "list",         - the type of the parameter value
      "serialize_unique": false,            - states if the object is unique or can have duplicates
      "classes": [                          - classes allowed in the parameter value
        "EntityType",
        "PartType"
      ],
      "drop": [                             - value parameters that are droped (e.g., "identification" is always
        "identification"                       dropped and set again in the import)
      ]
    },
    ...
    ],
  "sheets": [                               - sheets of e.g., the excel file
    {
      "name": "EntityType",                 - name of the excel file sheet
      "classes": [                          - classes inside the excel sheet
        "EntityType",
        "PartType"
      ],
      "columns": [                          - columns inside an excel sheet
        {
          "column_kind": "type",            - ToDo ???
          "description": "description",     - Describes the column/ parameter
          "notation": "notation",           - States the notation of the parameter
          "example": "example",             - Gives a modelling example
          "mandatory": "mandatory",         - States if the parameter is mandatory
          "name": "index",                  - Name of the parameter
          "format": "string"                - format of the parameter (ToDo: required in export?)
        },
        ...
        ],
    ],
}

Dynamic State Model Mapper json file

{
  "target_schema": "pkl",                   - resulting file type
  "reference_type": "identification",       - label means that the labels/ static model ids are used as reference
  "sources": [                              - parameters of the state model python object
    {
      "source": "entity_types",             - a parameter of the state model python object
      "serialization_kind": "list",         - the type of the parameter value
      "serialize_unique": false,            - states if the object is unique or can have duplicates
      "classes": [                          - classes allowed in the parameter value
        "EntityType",
        "PartType"
      ],
     {
        "source": "plant",
        "serialization_kind": "single_value",
        "serialize_unique": false,
        "classes": ["Plant"],
         "drop": [                          - value parameters that are droped
        "work_calendar"
      ]
    },
    ...
    ],
}

How To Serialize DigitalTwin

During the WS 23/24 we have written a Serializer for the digital twin. The Serializer is able to serialize the digital twin into a JSON file or an excel. There existed an old serializer to the excel format, but it was not able to serialize new attributes of the digital twin. The new serializer is able to serialize all attributes of the digital twin. Most of them are serialized automatically with default methods. All classes should have a dict_serialize method now, which is used to serialize objects of this class. In the following the development process is described.

Requirements

---

1. The serializer should be able to serialize all attributes of the digital twin to an excel file format.
2. Newly added attributes should be serialized automatically or throw a warning.
3. An importer for the excel files already exists. The serializer should be able to serialize the digital twin in the same format as the importer expects it. The importer can be fitted, but this is a complicated process.

Solution Design

---

A new serializer class is added to the project (Serializable). This class provides basic functionality needed for the serialization. Each class which needs to be serialized (e.g. the digital twin) inherits from this class. The class provides some methods for serialization objects:

1. serialize_dict: Serializes a dictionary. Checks on each item in the dictionary if it has dict_serialize. If this is the case the item is serialized. Same for the keys.
2. serialize_list: Calls dict_serialize on the list elements and returns a list of serialized elements.
3. serialize_2d_numpy_array: Serializes a 2d numpy array. Checks on each item in the array if it has dict_serialize. If this is the case the item is serialized.
4. serialize_list_of_tuple: Serializes a list of tuples. Checks on each item of the tuples in the list if it has dict_serialize. If this is the case the item is serialized.
5. dict_serialize: The main method of the class. Serializes the dict representation of a class to a json serializable dictionary. This method can and for the most classes should be overwritten, since at the current state it does not serialize the items in the dictionary. It only checks if the object has already been serialized (to avoid endless loops) and adds some items to the dictionary (version number of the serializer, object_type and a label). It has the option to remove private attributes from the dictionary. And lastly it has the option to drop specified attributes. (The subclass needs to have a attribute drop_before_serialization).
6. remove_private: Mainly used by dict_serialize. Removes private attributes (starting with at least one underscore) from a dictionary.
7. to_json: Calls dict_serialize internally. Then parses the returned dictionary to a json.
8. check_key_value_in_dict: Checks whether a key value pair is in a dict. Can be used to check whether an attribute has been serialized. Mainly used by dict_serialize. Public to allow specific implementations of dict_serialize in subclasses and checking for correct serialization of attributes.
9. warn_if_attributes_are_missing: Interface to check if all attributes have been serialized. Should be called at the end of every implementation of the dict_serialize.

Each class of the digital twin must provide a dict_serialize method. This method should serialize all attributes of the class. Attributes can be ignored by specifying them with their name in a list called drop_before_serialization as a class attribute. For complex attributes (which are not serializable by the json module) the method should call dict_serialize on them directly if possible. Otherwise most of the times some of the provided methods (see above) can be used. If not a custom implementation must be provided. The method should return a dictionary with the serialized attributes. The method should also call warn_if_attributes_are_missing at the end to check if all attributes have been serialized. If this is not the case a warning (Type: SerializableWarning) is thrown. A simple implementation can look like the following:

class Entity(DynamicDigitalTwinObject, Serializable):
    drop_before_serialization = ['dynamic_attributes']
    further_serializable = ['_entity_type', '_process_execution', ]

    ...

    def dict_serialize(self, serialize_private: bool = True,
                   deactivate_id_filter: bool = False,
                   use_label: bool = False,
                   use_label_for_situated_in: bool = True) -> Union[dict | str]:
        """
        Creates a dict representation of the object.
        Also serializes object in attributes by calling the function on them.

        :param serialize_private: Whether to serialize the private attributes.
            Defaults to True.
        :param use_label: Whether to use the label as only identifier of the object. Then a string is returned.
        :param use_label_for_situated_in: If set to true, only the static model id is used for the situated_in attribute
            of this class.
        :param deactivate_id_filter: Whether to check if an obj has already been serialized.
            Then the static model id is used. Defaults to False.

        :return: The dict representation of the entity type or the static model id.
            If use_label is set to true a str is returned.
        """
        object_dict = super().dict_serialize(serialize_private=serialize_private,
                                             use_label=use_label,
                                             deactivate_id_filter=deactivate_id_filter)
        # Check if only the label is returned
        # Could be the case because use_label is true
        # or because the object has already been serialized and the id filter is active
        if isinstance(object_dict, str):
            return object_dict

        # Here a special serialization of the situated_in attribute is done
        # This attribute leads to and endless loop most of the time, so only the label is
        # used. This could also be moved to the dict_serialize of Serializable in the
        # future. This has to be done for many classes.
        # Also some attributes are serialized by calling dict_serialize on them. These are also specified in a class  attribute (further_serializable). This is also a candidate to be moved to the dict_serialize of Serializable.
        for key, value in object_dict.items():
            if key == '_situated_in' and value is not None:
                if use_label_for_situated_in:
                    object_dict[key] = value.get_static_model_id()
                else:
                    object_dict[key] = value.dict_serialize()
            elif key in self.further_serializable and value is not None:
                object_dict[key] = value.dict_serialize()

        # Check if attributes are missing
        Serializable.warn_if_attributes_are_missing(list(self.__dict__.keys()),
                                                    ignore=self.drop_before_serialization,
                                                    dictionary=object_dict)
        return object_dict

Like this the serializer is able to serialize all attributes of the digital twin. In the next step there are two possible ways to save the serialization. The first case is a json file. At the moment this is useless, but was implemented for future use, since json is platform and programming language independent. The second case is an excel file. This is the format the importer expects. The excel file is created by the twin_exporter.py and the format can be specified in a json. This allows easy modification of the excel file in the future, without modification of the exporter itself. The expected format for the importer is already created as a json and can be found at: ./DigitalTwin/application/repository_services/default_aligned_mapping.json The exporter itself and the format of the json is documented in ....

Future Work

---

1. The default implementation dict_serialize, should be able to serialize some more special attributes automatically. For example the numpy arrays, dicts, lists, etc. Most of the necessary methods have already been implemented. This would allow to remove the dict_serialize method from most of the subclasses and just use the default implementation from the superclass. This is in theory an easy task, but in practice it is quite difficult, since the serializer is quite complex and it is not easy to check if the changes broke the serializer. It is also difficult to pinpoint the exact place where the changes broke the serializer. Since the output json is quite big and the excel only shows top level attributes and not the hierarchy.
2. More Testcases should be added (some are added from Adrian), to check if changes broke the serializer. Since the serializer is quite complex, breaking changes should be detected as early as possible.
3. The warning system should be improved. At the moment the warning is only thrown if an attribute is not serialized and removed from the dict and also the warning does not include information about the missing attribute and object. If it is not removed no warning is thrown (but probably if it is an important attribute an exception when trying to convert it to a json or excel) This should be improved. The warning should also be thrown if the dictionary representation includes attributes which are not a type supported by the json module (this means they are not serialized yet). This is quite complicated, since this needs to be checked recursively as well, however shouldn't be checked for attributes serialized by a subclass twice. The object could have an attribute which is a list and in the list are dicts and some value of the dict is not serialized yet. This is why we went the easy route at the beginning and only the check if each attribute is included in the keys of the dict. Time was at a premium. The implementation of the serializer for the complete digital twin and fitting to the importer needed a lot of time.
4. Move serialization of attributes like situated_in to the default implementation of dict_serialize.

Exporter

The overall idea is to write an exporter that takes in a mapping file that constitutes the target schema type and the structure of the schema originating in the source object (i.e. the DigitalTwin object) which implements dict_serialize. If the target schema is xlsx the mapping file should provide a sheets attribute that is a list of all sheets with its corresponding columns and mappings to the source object. A column mapping would consist of the column name as the key and the keys needed to access the value in the source object. When a list is provided the source object is accessed incrementally. I.e. ["entity_type", "name"] would lead to source["entity_type"]["name"]. The accessed value is stringified subsequently and written to the target table.

Defining sheets

By defining the target_schema as xlsx a sheets attribute can be provided as a list of sheets that should be included in the output of the exporter. A sheet definition follows the following scheme:

::

serialization_kind: "dict_flatten" | "list" | "single_value" | "mixed" serialize_unique: bool name: string source: string | list string filter: string source_function: string columns: list column start_row: int

Serialization kind

To address different types of source attributes for serialization a serialization kind is introduced:

• "serialization_kind" : "dict_flatten" -> Accepts source attributes of type dict[any, list[Serializable]] and flattens the dict whose keys map to lists to a single list. The list is serialized into the sheet
• "serialization_kind" : "list" -> Accepts source attributes of type list[Serializable] and serializes them directly to a table.
• "serialization_kind": "single_value" -> Accepts a source attribute that is impl Serializable and writes it to the target file. This is equivalent to "list" where the source list has one entry.
• "serialization_kind": "mixed" -> Accepts a source attribute that either meets the criteria of dict_flatten or list and reduces them to a single list which is being written to the target file.

Serialize unique

When serialize_unique is set to True the table only consists of unique values with an additional column amount that represents the amount of identical entries in the source.

Source

When a string is provided the provided input object is indexed by the string and is subsequently used as the source for the sheet. Providing a list of strings multiple source attributes of the input object can be used for the same sheet.

Filter

For each sheet a filter function can be provided to filter the source attribute. The filter function has to be supported by the exporter. The function has to return either True or False.

Source function

Source attributes can be mapped using a source function. The source function has to be supported by the exporter.

Start row

Specifies the first row which is used for writing to the target table.

Columns

A list of columns for the respective sheet. A column definition follows this schema:

::

column_kind: "simple" | "complex" | "fixed_value" | "generate" | "type" name: string function: string indexing_strategy: list string header: string

Column kind

The provided column kind tells the exporter how to handle elements in the list originating from the serialization kind of the source attribute. - Column kind type uses the indexing_strategy to iteratively index the element and writes the type of the element as values into the respective rows. - Column kind simple uses the indexing_strategy to iteratively index the element and writes the output to the target table. - Column kind complex uses the indexing_strategy to index the individual elements and applies a function to them - Column kind fixed_value writes a fixed value for each element into the column of the target table. - Column kind generate identifies each individual unique value resulting from indexing all elements and generates a new column for each of the unique values. Subsequently, the rows are filled with the count that results from counting the items in the element that matches the respective column.

Name

The column name that appears in the target table. Not needed for column_kind = "generate".

Function

The function that is applied to each individual element when column_kind = "complex".

Indexing strategy

A list of keys that are iteratively used to index each individual element, i.e. indexing_strategy = ["hello", "world"] the element would be indexed as follows: el["hello"]["world"]

Header

An optional attribute that lets you specify whether columns should be grouped. Columns with the same header are grouped together appearing next to each other with an additional header in the target table.

Example:

.. code-block:: json

{
  "target_schema": "xlsx",
  "sheets": [
    {
      "serialization_kind": "dict_flatten",
      "serialize_unique": true,
      "name": "StationaryResource",
      "source": "stationary_resources",
      "columns": [
        {
          "column_kind": "fixed_value",
          "name": "index",
          "value": "StationaryResource"
        }
      ]
    }
  ]
}
